2SK753 - N-Channel MOSFET Transistor

The 2SK753 by Inchange Semiconductor is a N-Channel MOSFET Transistor. Below is the official datasheet preview.

📥 Download Datasheet

Official preview page of the 2SK753 N-Channel MOSFET Transistor datasheet (Inchange Semiconductor).

Datasheet Details

Part number 2SK753
Manufacturer Inchange Semiconductor
File Size 233.08 KB
Description N-Channel MOSFET Transistor
Datasheet download datasheet 2SK753-InchangeSemiconductor.pdf
Additional preview pages of the 2SK753 datasheet.

2SK753 Product details

Description

Drain Current ID=5A@ TC=25℃ Drain Source Voltage- : VDSS= 160V(Min) 100% avalanche tested Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS High speed power switching ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL ARAMETER VALUE UNIT VDSS Drain-Source Voltage (VGS=0) 160 V VGS Gate-Source Voltage ±20 V ID Drain Current-continuous@ TC=25℃ 5 A Ptot Total Dissipation@TC=25℃ 40 W Tj Max.Operating Junction T
