2SK1563 - N-Channel MOSFET Transistor

📥 Download Datasheet

Preview of 2SK1563 PDF
datasheet Preview Page 2

Datasheet Details

Part number 2SK1563
Manufacturer Inchange Semiconductor
File Size 213.38 KB
Description N-Channel MOSFET Transistor
Datasheet download datasheet 2SK1563-InchangeSemiconductor.pdf

2SK1563 Product details

Description

Drain Current ID=12A@ TC=25℃ Drain Source Voltage- : VDSS=500 (Min) Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS Designed for high voltage, high speed power switching applications such as switching regulators, converters, solenoid and relay drivers.ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL ARAMETER VDSS Drain-Source Voltage (VGS=0) VALUE UNI T 500 V VGS Gate-Source Voltage ±30 V ID Drain Current-continuo
