2SD363 - Silicon NPN Power Transistor

Description

Collector-Emitter Breakdown Voltage- : V(BR)CEO= 120V(Min) Collector Power Dissipation- : PC= 40W(Max)@ TC= 25℃ Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS

Designed for B/W TV horizontal deflection output applications.

📥 Download Datasheet

📁 Similar Datasheet

  • 2SD360 - (2SD359 / 2SD360) NPN Transistor (ETC)
  • 2SD361 - NPN Transistor (ETC)
  • 2SD362 - Silicon NPN Power Transistors (SavantIC)
  • 2SD362 - NPN Transistor (INCHANGE)
  • 2SD365 - NPN Transistor (INCHANGE)
  • 2SD30 - NPN Transistor (Sanyo Semiconductor)
  • 2SD310 - NPN Transistor (INCHANGE)
  • 2SD312 - NPN Transistor (INCHANGE)
  • 2SD313 - NPN Transistor (UTC)
  • 2SD313 - SILICON POWER TRANSISTOR (SavantIC)
Other Datasheets by Inchange Semiconductor
  • 2SD311 - Silicon NPN Power Transistor
  • 2SD380 - Silicon NPN Power Transistor
  • 2SD103 - Silicon NPN Power Transistors
  • 2SD1032 - Silicon NPN Power Transistor
  • 2SD1044 - Silicon NPN Darlington Power Transistor
  • 2SD1071 - Silicon NPN Transistor
  • 2SD1113 - Silicon NPN Power Transistor
  • 2SD1117 - Silicon NPN Power Transistor

Full PDF Text Transcription

Click to expand full text
isc Silicon NPN Power Transistor DESCRIPTION ·Collector-Emitter Breakdown Voltage- : V(BR)CEO= 120V(Min) ·Collector Power Dissipation- : PC= 40W(Max)@ TC= 25℃ ·Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS ·Designed for B/W TV horizontal deflection output applications. ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage 300 V VCEO Collector-Emitter Voltage 120 V VEBO Emitter-Base Voltage 8 V IC Collector Current-Continuous PC Collector Power Dissipation @ TC=25℃ TJ Junction Temperature 6 A 40 W 150 ℃ Tstg Storage Temperature Range -55~150 ℃ 2SD363 isc website：www.iscsemi.
