2SA1943 - POWER TRANSISTOR

The 2SA1943 by Inchange Semiconductor is a POWER TRANSISTOR. Below is the official datasheet preview.

📥 Download Datasheet

Official preview page of the 2SA1943 POWER TRANSISTOR datasheet (Inchange Semiconductor).

Datasheet Details

Part number 2SA1943
Manufacturer Inchange Semiconductor
File Size 204.72 KB
Description POWER TRANSISTOR
Datasheet download datasheet 2SA1943_InchangeSemiconductor.pdf
Additional preview pages of the 2SA1943 datasheet.

2SA1943 Product details

Description

High Current Capability High Power Dissipation High Collector-Emitter Breakdown Voltage- : V(BR)CEO=- 230V(Min) Complement to Type 2SC5200 Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS Power amplifier applications Recommend for 100W high fidelity audio frequency amplifier output stage applications ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage -230 V VCEO Coll
