WESTCODE
An IXYS Company
Date:- 22nd July, 2009 Data Sheet Issue:- 2
Provisional Data
Rectifier Diode Types W7045MC030 to W7045MC060
Development part number Wx248MC030-060
Absolute Maximum Ratings
VRRM VRSM
VOLTAGE RATINGS
Repetitive peak reverse voltage, (note 1) Non-repetitive peak reverse voltage, (note 1)
MAXIMUM LIMITS
300-600
400-700
UNITS
V V
OTHER RATINGS
IF(AV)M IF(AV)M IF(AV)M IF(RMS)M IF(d.c.) IFSM IFSM2 I2t I2t
Tj op Tstg
Maximum average forward current, Tsink=55°C, (note 2) Maximum average forward current. Tsink=100°C, (note 2) Maximum average forward current. Tsink=100°C, (note 3) Nominal RMS forward current, Tsink=25°C, (note 2) D.C.
