MMO175 Datasheet (IXYS) - AC Controller Modules

MMO175, AC Controller Modules

AC Controller Modules Preliminary Data VRSM VDSM V 1300 1700 VRRM VDRM V 1200 1600 Typ MMO 175-12io7 MMO 175-16io7 MMO 175 A I/H G/F N IRMS = 175 A ITAVM = 80 A VRRM = 1200/1600 V Symbol Conditions Maximum Ratings IRMS ITRMS ITAVM ITSM I2t (di/dt)cr (dv/dt)cr PGM PGAVM VRGM TVJ TVJM Tstg VISOL Md TC = 85°C; 50-400 Hz (per single controller) TC = 85°C; 180° sine TVJ = 45°C; t = 10 ms (50 Hz) VR = 0 t = 8.3 ms (60 Hz) TVJ = 125°C; t = 10 ms (50 Hz) VR = 0 t = 8.3 ms (60 Hz) T
