K1351VF600 - Medium Voltage Thyristor

Download the K1351VF600 datasheet PDF. This datasheet also covers the K1351VC600 variant, as both devices belong to the same medium voltage thyristor family and are provided as variant models within a single manufacturer datasheet.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (K1351VC600-IXYS.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
K1351 2SK1351 ETC
K135 2SK135 Hitachi Semiconductor
K1350 2SK1350 ETC
K1356 2SK1356 ETC
K1357 2SK1357 ETC

Other Datasheets by IXYS (Littelfuse)

Part Number Description
K1351VF620 Medium Voltage Thyristor
K1351VF640 Medium Voltage Thyristor
K1351VF650 Medium Voltage Thyristor
K1351VC600 Medium Voltage Thyristor
K1351VC620 Medium Voltage Thyristor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
   WESTCODE An IXYS Company Date:- 26 May, 2005 Data Sheet Issue:- 1 Provisional Data Medium Voltage Thyristor Types K1351V#600 to K1351V#650 (Development part No.: KX120V#600-650) Absolute Maximum Ratings VDRM VDSM VRRM VRSM VOLTAGE RATINGS Repetitive peak off-state voltage, (note 1) Non-repetitive peak off-state voltage, (note 1) Repetitive peak reverse voltage, (note 1) Non-repetitive peak reverse voltage, (note 1) MAXIMUM LIMITS 6000-6500 6000-6500 6000-6500 6100-6600 UNITS V V V V OTHER RATINGS IT(AV)M IT(AV)M IT(AV)M IT(RMS) IT(d.c.) ITSM ITSM2 I2t I2t (di/dt)cr VRGM PG(AV) PGM Tj op Tstg Maximum average on-state current, Tsink=55°C, (note 2) Maximum average on-state current. Tsink=85°C, (note 2) Maximum average on-state current.
