IS65WV10248EBLL - ULTRA LOW POWER CMOS STATIC RAM

Download the IS65WV10248EBLL datasheet PDF. This datasheet also covers the IS62WV10248EALL variant, as both devices belong to the same ultra low power cmos static ram family and are provided as variant models within a single manufacturer datasheet.

Description

The ISSI IS62WV10248EALL/ IS62WV10248EBLL are high-speed, 8M bit static RAMs organized as 1M words by 8 bits.

It is fabricated using ISSI's high-performance CMOS technology.

Features

  • High-speed access time: 45ns, 55ns.
  • CMOS low power operation.
  • 36 mW (typical) operating.
  • 12 µW (typical) CMOS standby.
  • TTL compatible interface levels.
  • Single power supply.
  • 1.65V-2.2V VDD (62/65WV10248EALL).
  • 2.2V-3.6V VDD (62/65WV10248EBLL).
  • Data control for upper and lower bytes.
  • Automotive temperature (-40oC to +125oC).
  • Lead-free available BLOCK.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (IS62WV10248EALL-ISSI.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
IS65WV102416BLL 1M x 16 HIGH-SPEED LOW POWER ASYNCHRONOUS CMOS STATIC RAM Integrated Silicon Solution
IS65C256AL 32K x 8 LOW POWER CMOS STATIC RAM Integrated Silicon Solution
IS65C51216AL ULTRA LOW POWER CMOS STATIC RAM Integrated Silicon Solution
IS65C6416AL 64K x 16 HIGH-SPEED CMOS STATIC RAM Integrated Silicon Solution
IS65LV256AL 32K x 8 LOW VOLTAGE CMOS STATIC RAM Integrated Silicon Solution

Other Datasheets by ISSI (now Infineon)

Part Number Description
IS65WV10248EALL ULTRA LOW POWER CMOS STATIC RAM
IS65WV10248DALL ULTRA LOW POWER CMOS STATIC RAM
IS65WV10248DBLL ULTRA LOW POWER CMOS STATIC RAM
IS65WV10248HALL ULTRA LOW POWER CMOS STATIC RAM
IS65WV10248HBLL ULTRA LOW POWER CMOS STATIC RAM

Full PDF Text Transcription

Click to expand full text
IS62WV10248EALL/BLL IS65WV10248EALL/BLL 1Mx8 LOW VOLTAGE, ULTRA LOW POWER CMOS STATIC RAM NOVEMBER 2014 KEY FEATURES  High-speed access time: 45ns, 55ns  CMOS low power operation – 36 mW (typical) operating – 12 µW (typical) CMOS standby  TTL compatible interface levels  Single power supply –1.65V-2.2V VDD (62/65WV10248EALL) – 2.2V-3.6V VDD (62/65WV10248EBLL)  Data control for upper and lower bytes  Automotive temperature (-40oC to +125oC)  Lead-free available BLOCK DIAGRAM DESCRIPTION The ISSI IS62WV10248EALL/ IS62WV10248EBLL are high-speed, 8M bit static RAMs organized as 1M words by 8 bits. It is fabricated using ISSI's high-performance CMOS technology.
