IS25LQ020, IS25LQ040 4Mbit Single Operating Voltage Serial Flash Memory

IS25LQ020 Description

IS25LQ020/040 2 Mbit / 4 Mbit Single Operating Voltage Serial Flash Memory With 104 MHz Dual- or 100MHz Quad-Output SPI Bus Interface PRELIMINARY DAT.
The IS25LQ020/040 is 2 Mbit / 4 Mbit Serial Peripheral Interface (SPI) Flash memories, providing single-, dual or quad-output.

IS25LQ020 Features

* Single Power Supply Operation - Low voltage range: 2.3 V - 3.6 V
* Memory Organization - IS25LQ020: 256K x 8 (2 Mbit) - IS25LQ040: 512K x 8 (4 Mbit)
* Cost Effective Sector/Block Architecture - 2Mb / 4Mb : Uniform 4KByte sectors / sixteen uniform 64KByte blocks
* Se

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: IS25LQ020, IS25LQ040. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
IS25LQ020, IS25LQ040
Manufacturer
ISSI
File Size
1.43 MB
Datasheet
IS25LQ040-ISSI.pdf
Description
4Mbit Single Operating Voltage Serial Flash Memory
Note
This datasheet PDF includes multiple part numbers: IS25LQ020, IS25LQ040.
Please refer to the document for exact specifications by model.
