Description
The IQXC-137 is a low profile SMD AT-cut quartz crystal in a ceramic package with a 2.5 x 2.0mm footprint.
Features
- Excellent shock and vibration performance Low ageing
Frequency Parameters
Frequency
16.368MHz to 52.0MHz
Frequency Tolerance
±10.00ppm to ±50.00ppm
Tolerance Condition
@ 25°C ±2°C
Frequency Stability
±10.00ppm to ±50.00ppm
Ageing
±1ppm max per year @ 25°C
Reflow shift (Two consecutive reflow as per profile after 4
hours recovery at 25°C): ±1ppm max
Frequency stability over temperature referenced to frequency
reading at 25˚C and the specified load capacitance. Frequency perturbat.
