ICVE10184E150R201FR - ESD FILTER

Features

  • 4 EMI filter lines per device.
  • Multilayer chip EMI suppression filter utilizing π.
  • type circuit.
  • Very thin (max. 0.50t) and low space consuming(1.6X0.8mm2) size.
  • Steep attenuation characteristic plot, Highly effective noise suppression.
  • Covers a wide range of frequencies.
  • No asymmetrical degradation.
  • Simpler fabricating process than diode-type filters.
  • Soldering of plating type terminations guarantee high phys.
