VN1206N5 N-Channel MOSFET

INCHANGE

VN1206N5 Description

isc N-Channel MOSFET Transistor *.

VN1206N5 Features

* With TO-220 packaging
* High speed switching
* Low gate input resistance
* Standard level gate drive
* Easy to use
* 100% avalanche tested
* Minimum Lot-to-Lot variations for robust device performance and reliable operation

VN1206N5 Applications

* Power supply
* Switching applications
* ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE VDSS Drain-Source Voltage 60 VGSS Gate-Source Voltage ±20 ID Drain Current-Continuous 9 IDM Drain Current-Single Pulsed 35 PD Total Dissipation 45 Tj Operating Junction Tem

📥 Download Datasheet

VN1206N5 Datasheet Preview — Preview of VN1206N5 PDF

Datasheet Details

Part number: VN1206N5
Manufacturer: INCHANGE
File Size: 255.64 KB
Datasheet: VN1206N5-INCHANGE.pdf
Description: N-Channel MOSFET
