IRF1407S N-Channel MOSFET

IRF1407S Description

Isc N-Channel MOSFET Transistor IRF1407S *.

IRF1407S Features

* With To-263(D2PAK) package
* Low input capacitance and gate charge
* Low gate input resistance
* 100% avalanche tested
* Minimum Lot-to-Lot variations for robust device performance and reliable operation

IRF1407S Applications

* Switching applications
* ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE VDSS Drain-Source Voltage 75 VGSS ID IDM Gate-Source Voltage Drain Current-ContinuousTc=25℃ Tc=100℃ Drain Current-Single Pulsed ±20 100 70 520 PD Total Dissipation @TC=25℃ 200 Tch Max. Operating J

📥 Download Datasheet

Preview of IRF1407S PDF
datasheet Preview Page 2

Datasheet Details

Part number
IRF1407S
Manufacturer
INCHANGE
File Size
253.85 KB
Datasheet
IRF1407S-INCHANGE.pdf
Description
N-Channel MOSFET
