IPP90R500C3 - N-Channel MOSFET

INCHANGE

📥 Download Datasheet

IPP90R500C3 Datasheet Preview — Preview of IPP90R500C3 PDF

Datasheet Details

Part number	IPP90R500C3
Manufacturer	INCHANGE
File Size	241.67 KB
Description	N-Channel MOSFET
Datasheet	IPP90R500C3-INCHANGE.pdf

IPP90R500C3 Product details

Description

High peak current capability Ultra low gate charge ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE VDSS Drain-Source Voltage 900 VGS Gate-Source Voltage ±20 ID Drain Current-Continuous 11 IDM Drain Current-Single Pulsed 24 PD Total Dissipation @TC=25℃ 156 Tj Max.Operating Junction Temperature 150 Tstg Storage Temperature -55~150 UNIT V V A A W ℃ ℃ THERMAL CHARACTERISTICS SYMBOL PARAMETER Rth(ch-c) Channel-to-case thermal resistance Rth(

Features

br>.
Static drain-source on-resistance: RDS(on) ≤0.5Ω.
Enhancement mode.
Fast Switching Speed.
100% avalanche tested.
Minimum Lot-to-Lot variations for robust device performance and reliable operation.
