IZ1517 - Supply Vlotage(V) : 2.0~3.6

IK Semiconductor

📥 Download Datasheet

IZ1517 Datasheet Preview — Preview of IZ1517 PDF

datasheet Preview Page 2

Datasheet Details

Part number	IZ1517
Manufacturer	IK Semiconductor
File Size	86.51 KB
Description	Supply Vlotage(V) : 2.0~3.6
Datasheet	IZ1517_IKSemiconductor.pdf

IZ1517 Product details

Features

w w.
Single 3V battery operation.
Random or sequence flash selection.
Low stand-by current.
Built in oscillator.
Oscillator’s resistor internal or external (maskoption).
Toggle ON/OFF control or one shot mode.
One shot duration is about 8 seconds (metal mask option).
1/10 ON/OFF duty cycle output.
Direct drive LEDs (open-drain output) at . D w h S a ee U 4 t m o . c.
