HD66710 - (Dot Matrix Liquid Crystal Display Controller/Driver)

General Description

The HD66710 dot-matrix liquid crystal display controller and driver LSI displays alphanumerics, numbers, and symbols.

It can be configured to drive a dot-matrix liquid crystal display under the control of a 4- or 8-bit microprocessor.

Key Features

  • 5 × 8 dot matrix possible.
  • Low power operation support:  2.7V to 5.5V (low voltage).
  • Booster for liquid crystal voltage  Two/three times (13V max. ).
  • Wide range of liquid crystal display driver voltage  3.0V to 13V.
  • Extension driver interface.
  • High-speed MPU bus interface (2 MHz at 5-V operation).
  • 4-bit or 8-bit MPU interface capability.
  • 80 × 8-bit display RAM (80 characters max. ) 291 HD66710.
  • 9,600-bit charact.
