HD40L4240P - CMOS 4bit single-chip microcomputers

Name: HD40L4240P
SKU: HD40L4240P-81262

Hitachi Semiconductor

📥 Download Datasheet

HD40L4240P Datasheet Preview — Preview of HD40L4240P PDF

Datasheet Details

Part number	HD40L4240P
Manufacturer	Hitachi Semiconductor
File Size	111.27 KB
Description	CMOS 4bit single-chip microcomputers
Datasheet	HD40L4240P_HitachiSemiconductor.pdf

HD40L4240P Product details

Description

The HD66100F description segment driver with 80 LCD drive circuits is the improved version of the no longer current HD44100H LCD driver with 40 circuits.

Features

LCD driver with serial/parallel converting function.
Interface compatible with the HD44100H; connectable with HD43160AH, HD61830, HD61830B, LCD-II (HD44780), LCD-III (HD44790).
Internal output circuits for LCD drive: 80.
Internal serial/parallel converting circuits  80-bit bidirectional shift register  80-bit latch circuit.
Power supply  Internal logic circuit: +5V ±10%  LCD drive circuit: 3.0V to 6.0V.
CMOS process 109 HD66100F Compar.
