Download the H7805AA datasheet PDF. This datasheet also covers the H7805AA_Hi variant, as both devices belong to the same 3-terminal positive voltage regulator family and are provided as variant models within a single manufacturer datasheet.
These regulators employ internal current-limiting and thermalshutdown, making them essentially indestructible.
They can deliver up to 100mA output current.
if the case temperature can keep in Tc=25°C.
| Part number | H7805AA |
|---|---|
| Manufacturer | Hi-Sincerity Mocroelectronics |
| File Size | 36.88 KB |
| Description | 3-TERMINAL POSITIVE VOLTAGE REGULATOR |
| Datasheet |
 H7805AA Datasheet
|
|
|
