HDMs64gs24_-2 - LCD DISPLAY MODULE

HANTRONIX

📥 Download Datasheet

HDMs64gs24_-2 Datasheet Preview — Preview of HDMs64gs24_-2 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	HDMs64gs24_-2
Manufacturer	HANTRONIX
File Size	129.64 KB
Description	LCD DISPLAY MODULE
Datasheet	HDMs64gs24_-2_HANTRONIX.pdf

HDMs64gs24_-2 Product details

Features

of HDM64GS24_-2 (1) Low power consumption 5.0V power supply (2) 1/64 duty, 1/9 bias (3) Viewing direction: 6:00 / 12:00 O’clock (4) Operating temperature : Normal (0~50 °C) / Extended (-20~70 °C) (5) Storage temperature : Normal (-20~70 °C) / Extended (-30~85 °C) (6) Display type: FSTN / STN , Positive / Negative (7) DC-to-DC Converter : Built-in (8) Controller : Toshiba T6963C 2. Mechanical Data and Conditions: (1) Number of Characters ------------ 240 Dots.
64 Dots Graphic LCD Module.
