ZMM13 - Silicon Planar Zener Diodes

Features

  • Silicon Planar Zener Diodes.
  • In Mini-MELF case especially for automatic insertion. .142 (3.6) .134 (3.4) .019 (0.48) .011 (0.28) ∅ .063 (1.6) .055 (1.4) Cathode Mark.
  • The Zener voltages are graded according to the international E 24 standard. Smaller voltage tolerances and other Zener voltages are available upon request.
  • These diodes are also available in DO-35 case with the type designation ZPD1 … ZPD51. Dimensions are in inches and (millimeters) MEC.
