BAV19WS - SMALL SIGNAL DIODES

General Semiconductor

Datasheet Details

Part number	BAV19WS
Manufacturer	General Semiconductor
File Size	118.34 KB
Description	SMALL SIGNAL DIODES
Datasheet	BAV19WS_GeneralSemiconductor.pdf

Silicon Epitaxial Planar Diodes.
For general purpose.
These diodes are also available in other case styles including: the DO-35 case with the type designations BAV19 to BAV21, the Mini-MELF case with the type designations BAV100 to BAV103, the SOT-23 case with the type designation BAS19 - BAS21 and the SOD-123 case with the type designation BAV19W-BAV21W. .012 (0.3) .112 (2.85) .100 (2.55) .076 (1.95) .065 (1.65) Cathode Mark Top View max. .049 (1.25) max. .004.
