CDP68EM05C4 - CMOS High-Performance Silicon-Gate 8-Bit Microcomputer Piggyback Emulator

Features

  • All CDP68HC05C4 hardware and software features.
  • Un-multiplexed external address, data, and READ control lines.
  • Full8K byte address space available (7984 bytes available externally).
  • 176 bytes of on-chip RAM, no ROM.
  • Direct interface to industry standard EPROMs.
  • 4D-lead.

📥 Download Datasheet

Datasheet Details

Part number CDP68EM05C4
Manufacturer GE
File Size 233.71 KB
Description CMOS High-Performance Silicon-Gate 8-Bit Microcomputer Piggyback Emulator
Datasheet download datasheet CDP68EM05C4 Datasheet
