7MBR35XPA120-50
Power Module(X series) 1200V / 35A / PIM
◼ Feactures Low V CE(sat) Compact Package P.C.Board Mount Module Converter Diode Bridge Dynamic Brake Circuit RoHS compliant Product
◼Applications Inverter for Motor Drive AC and DC Servo Drive Amplifier Uniterruptible Power Supply
◼ Outline drawing ( Unit : mm )
IGBT Modules ◼ Typical appearance
shows theoretical dimensio ( ) shows reference dimension
Indication on module
◼ Equivalent circuit
[ Converter ]
[ Brake]
[ Inverter ]
Weight: 200 g (typ.
7MBR35XPA120-50 Datasheet
