MCF51JM32 - Microcontroller

Download the MCF51JM32 datasheet PDF. This datasheet also covers the MCF51JM128 variant, as both devices belong to the same microcontroller family and are provided as variant models within a single manufacturer datasheet.

Features

  • the following functional units:.
  • V1 ColdFire core with background debug module Up to 128 KBytes of flash memory Up to 16 Kbytes of static RAM (SRAM) Multipurpose clock generator (MCG) Dual-role Universal Serial Bus On-The-Go device (USBOTG) Controller-area network (MSCAN) Cryptographic acceleration unit (CAU).

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (MCF51JM128_FreescaleSemiconductor.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
MCF51JE128 high-performance ColdFire V1 family of 32-bit microcontrollers(MCUs) Motorola Semiconductor
MCF51JE256 high-performance ColdFire V1 family of 32-bit microcontrollers(MCUs) Motorola Semiconductor
MCF51AG128 ColdFire Microcontroller NXP
MCF51EM256 ColdFire Microcontroller NXP
MCF5206 MCF5206 Integrated Microprocessor Motorola

Other Datasheets by Freescale Semiconductor (now NXP Semiconductors)

Part Number Description
MCF51JM128 Microcontroller
MCF51JM64 Microcontroller
MCF51JF128 Microcontrollers
MCF51JU128 Microcontrollers
MCF51AC128A Microcontroller

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Freescale Semiconductor Data Sheet: Technical Data Document Number: MCF51JM128 Rev. 2, 09/2008 MCF51JM128 80 LQFP 14 mm × 14 mm 64 LQFP 10 mm × 10 mm MCF51JM128 ColdFire Microcontroller www.DataSheet4U.com 44 LQFP 10 mm × 10 mm 64 QFP 14 mm × 14 mm The MCF51JM128 is a member of the ColdFire® family of 32-bit reduced instruction set computing (RISC) microprocessors. This document provides an overview of the MCF51JM128 series, focusing on its highly integrated and diverse feature set. The MCF51JM128 series is based on the V1 ColdFire core and operates at processor core speeds up to 50.33 MHz. As part of Freescale’s Controller Continuum®, it is an ideal upgrade for designs based on the MC9S08JM60 series of 8-bit microcontrollers.
