AO8801A - P-Channel MOSFET

General Description

The AO8801A uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate voltages as low as 1.8V.

This device is suitable for use as a load switch or in PWM applications.

Key Features

  • VDS ID (at VGS=-10V) RDS(ON) (at VGS= -4.5V) RDS(ON) (at VGS= -2.5V) RDS(ON) (at VGS= -1.8V) -20V -4.5A < 42mΩ < 54mΩ < 68mΩ D1 D2 Top View D1 S1 S1 G1 1 2 3 4 8 7 6 5 D2 S2 S2 G2 G1 G2 S1 S2 C unless otherwise noted Absolute Maximum Ratings TA=25° Parameter Symbol Drain-Source Voltage VDS Gate-Source Voltage Continuous Drain Current Pulsed Drain Current Power Dissipation B C Maximum -20 ±8 -4.5 -3.6 -30 1.5 0.96 -55 to 150 Units V V A VGS TA=25° C C TA=70° TA=25° C C TA=70° ID IDM PD.
