RFP50N05L - N-Channel MOSFET

Features

  • 50A, 50V.
  • rDS(ON) = 0.022Ω.
  • UIS SOA Rating Curve (Single Pulse).
  • Design Optimized for 5V Gate Drive.
  • Can be Driven Directly from CMOS, NMOS, TTL Circuits.
  • Compatible with Automotive Drive Requirements.
  • SOA is Power Dissipation Limited.
  • Nanosecond Switching Speeds.
  • Linear Transfer Characteristics.
  • High Input Impedance.
  • Majority Carrier Device.
  • Related Literature - TB334 “Guidelines for Sol.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
RFP50N05L N-Channel MOSFET Intersil Corporation
RFP50N05 N-Channel MOSFET Intersil Corporation
RFP50N06 N-Channel MOSFET Intersil Corporation
RFP50N06 Avalanche Rated N-Channel Enhancement-Mode Power MOSFETs Harris
RFP50N06 N-Channel Power MOSFET ON Semiconductor

Other Datasheets by Fairchild (onsemi)

Part Number Description
RFP50N06 N-Channel MOSFET
RFP12N06 N-Channel Power MOSFET
RFP12N06RLE N-Channel Power MOSFET
RFP12N10L N-Channel Power MOSFET
RFP14N05 N-Channel Power MOSFET

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
RFG50N05L, RFP50N05L Data Sheet January 2002 50A, 50V, 0.022 Ohm, Logic Level, N-Channel Power MOSFETs These are logic-level N-channel power MOSFETs manufactured using the MegaFET process. This process, which uses feature sizes approaching those of LSI integrated circuits gives optimum utilization of silicon, resulting in outstanding performance. They were designed for use with logic-level (5V) driving sources in applications such as programmable controllers, automotive switching, switching regulators, switching converters, motor relay drivers and emitter switches for bipolar transistors.
