ESIC04065S - Silicon carbide power schottky diode

Product Overview

Eris

📥 Download Datasheet

ESIC04065S Silicon carbide power schottky diode by Eris - Datasheet Preview — Datasheet preview – ESIC04065S

Datasheet Details

Part number	ESIC04065S
Manufacturer	Eris
File Size	308.59 KB
Description	Silicon carbide power schottky diode
Datasheet	ESIC04065S Datasheet
Additional preview pages of the ESIC04065S datasheet.

Product details

Features

‧Rated to 650V at 4 Amps ‧Zero reverse recovery current ‧Zero forward recovery voltage ‧Temperature independent switching behaviour ‧High temperature operation ‧High frequency operation ‧Marking : ESIC04065S Ordering Information Part No. Package ESIC04065S TO-220AC Packing 50 / Tube Benefits ‧Unipolar rectifier ‧Substantially reduced switching losses ‧No thermal run-away with parallel devices ‧Reduced heat sink requirements.
