EL4442C - Multiplexed-Input Video Amplifiers

Product Overview

Elantec Semiconductor

Part number	EL4442C
Manufacturer	Elantec Semiconductor
File Size	318.73 KB
Description	Multiplexed-Input Video Amplifiers
Datasheet	EL4442C Datasheet
Note	This datasheet PDF includes multiple part numbers: EL4442C, EL4422C. Please refer to the document for exact specifications by model.
Additional preview pages of the EL4442C datasheet.

Unity or a 2-gain bandwidth of 80 MHz 70 dB off-channel isolation at 4 MHz Directly drives high-impedance or 75X loads 02% and 02 differential gain and phase errors 8 ns switching time k100 mV switching glitch 0 2% loaded gain error Compatible with g3V to g15V supplies 160 mW maximum dissipation at g5V supplies Ordering Information Part No Temp Range Package Outline EL4421CN b40 C to a85 C 8-Pin PDIP MDP0031 EL4421CS b40 C to a85 C 8-Pin SO MDP0027 EL4422CN b40 C to a85 C 8-Pin.
