EM9202 - Worlds First Fully Integrated Single-Cell Battery 2.4GHz Transceiver

Download the EM9202 datasheet PDF (EM9201 included). The manufacturer datasheet provides complete specifications, pinout details, electrical characteristics, and typical applications for worlds first fully integrated single-cell battery 2.4ghz transceiver.

Description

The EM9201/02 is a low-voltage 2.4GHz transceiver IC with built-in link-layer logic permitting proprietary wireless links in the 2.400 … 2.485 GHz ISM band.

Features

  • Single cell 1.5V battery operation (Alkaline AA, AAA) Operation down to VBAT = 0.8 V (for start-up --> 1.0V) 3 V Lithium battery as alternative Bluetooth Low Energy-compliant GFSK modulation Low drift of PLL frequency by design On air data rate: 1Mb/s for EM9201, configurable 1Mb/s or 2Mb/s for EM9202. Programmable RF output level: -20 dBm … + 4dBm in 8 steps No antenna matching elements needed through appropriate PCB antenna design : 200 Ω differential impedance of antenna port Low-cost 26MHz X.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (EM9201_EMMicroelectronic.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number EM9202
Manufacturer EM Microelectronic
File Size 1.04 MB
Description Worlds First Fully Integrated Single-Cell Battery 2.4GHz Transceiver
Datasheet download datasheet EM9202 Datasheet

📁 Similar Datasheet

  • EM92547A - CALLER ID FSK DECODER (ELAN Microelectronics Corp)
  • EM92547B - CALLER ID FSK DECODER (ELAN Microelectronics Corp)
  • EM92547D - CALLER ID FSK DECODER (ELAN Microelectronics Corp)
  • EM92600A - DUAL PLL FOR 46/49 MHZ CORDLESS PHONE (ELAN Microelectronics Corp)
  • EM92601A - DUAL PLL FOR 46/49 MHZ CORDLESS PHONE (ELAN Microelectronics Corp)
  • EM9010 - Advanced Multimedia Analog Overlay Chip (Sigma Designs)
  • EM9038 - Analog Multiplexor And Digital-to-analog Converter (Sigma Designs)
  • EM91203 - TONE/PULSE SWITCHABLE DIALER WITH LCD INTERFACE (ELAN Microelectronics Corp)
  • EM91203A - TONE/PULSE SWITCHABLE DIALER WITH LCD INTERFACE (ELAN Microelectronics Corp)
  • EM91203B - TONE/PULSE SWITCHABLE DIALER WITH LCD INTERFACE (ELAN Microelectronics Corp)
Other Datasheets by EM Microelectronic
  • EM9201 - Low power 2.4 GHz Transceiver
  • EM9203 - 2.4GHz GFSK Transceiver
  • EM9209 - FSK Transceiver
  • EM9301 - Single-Cell Battery Bluetooth Low-Energy Controller
  • EM9304 - Bluetooth5.0 low-energy COMPANION-or-SOC
  • EM9305 - BLUETOOTH LE SOC AND COMPANION CHIP

Full PDF Text Transcription

Click to expand full text
EM MICROELECTRONIC - MARIN SA www.DataSheet4U.com EM9201/02 World’s First Fully Integrated Single-Cell Battery 2.4 GHz Transceiver Description The EM9201/02 is a low-voltage 2.4GHz transceiver IC with built-in link-layer logic permitting proprietary wireless links in the 2.400 … 2.485 GHz ISM band. It has a radio core with a low-IF architecture and GFSK modulation scheme being compliant with the emerging Bluetooth low energy technology standard. Control of the link-layer logic is possible though the SPI interface using an external host-controller. An FPGA bridge is included in the circuit such that with an external FPGA any protocol compatible with the RF characteristics can also be emulated through the SPI port of the EM9201/02. The EM9201/02 can be operated from a single 1.
