EV4-14D681K - 14mm Zinc Oxide Varistor

Download the EV4-14D681K datasheet PDF (EV4-14D180L included). The manufacturer datasheet provides complete specifications, pinout details, electrical characteristics, and typical applications for 14mm zinc oxide varistor.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (EV4-14D180L-ELECSOUND.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number EV4-14D681K
Manufacturer ELECSOUND
File Size 180.14 KB
Description 14mm Zinc Oxide Varistor
Datasheet download datasheet EV4-14D681K Datasheet

📁 Similar Datasheet

Other Datasheets by ELECSOUND

Full PDF Text Transcription

Click to expand full text
Varistor (MOV) EV4 - 14mm Zinc Oxide Varistor ELECSOUND® Wide Operating voltage (V1mA) range from 18V~1800V Withstanding Surge Current: 1000~6500A Model Size: 14mm Fast responding to transient over-voltage<25ns Low Clamping ratio and no following-on current Rohs Compliant Transistor,Diode, IC, Thyristor or diac semiconductor protection Surge protection in consumer electronics Surge protection in industrial electronics Surge protection in electronic home appliance, gas and petroleum. Relay and electromangnetic valve surge absorption How To Order EV4 MARKing 14 Chip Diameter 05 : 5mm 07 : 7mm 10 : 10mm 14 : 14mm 20 : 20mm Diameter And Size(Unit: mm) Voltage 180K-680K 820K-201K 221K-331K 361K-471K 511K-561K 621K-681K 751K-821K 911K-122K 142K-162K 182K B (Max.
