SMAJ18CAQ, SMAJ5.0AQ - 400W SURFACE MOUNT AUTOMOTIVE TRANSIENT VOLTAGE SUPPRESSOR

Diodes

The SMAJ18CAQ by Diodes is a 400W SURFACE MOUNT AUTOMOTIVE TRANSIENT VOLTAGE SUPPRESSOR. Below is the official datasheet preview.

📥 Download Datasheet

SMAJ18CAQ 400W SURFACE MOUNT AUTOMOTIVE TRANSIENT VOLTAGE SUPPRESSOR by Diodes - Datasheet Preview — Official preview page of the **SMAJ18CAQ** 400W SURFACE MOUNT AUTOMOTIVE TRANSIENT VOLTAGE SUPPRESSOR datasheet (Diodes).

Datasheet Details

Part number	SMAJ18CAQ, SMAJ5.0AQ
Manufacturer	DIODES
File Size	369.65 KB
Description	400W SURFACE MOUNT AUTOMOTIVE TRANSIENT VOLTAGE SUPPRESSOR
Datasheet	SMAJ5.0AQ-Diodes.pdf
Note	This datasheet PDF includes multiple part numbers: SMAJ18CAQ, SMAJ5.0AQ. Please refer to the document for exact specifications by model.
Additional preview pages of the SMAJ18CAQ datasheet.

SMAJ18CAQ Product details

Description

and Applications Suitable to protect sensitive automotive circuits against surges defined in ISO7637-2 and against electrostatic discharges according to ISO10605. Compliance with following standards ISO10605, C = 150pF, R = 330Ω: 30kV (Air Discharge) 30kV (Contact Discharge) ISO7637-2 (Note 5) Pulse 1: VS = -100V Pulse 2a: VS = +50V Pulse 3a: VS = -150V Pulse 3b: VS = +100V Mechanical Data Case: SMA Case Material: Molded Plastic UL Flammability Classifica

Features

400W Peak Pulse Power Dissipation.
5V to 200V Standoff Voltages.
Glass Passivated Die Construction.
Unidirectional and Bidirectional Versions Available.
Excellent Clamping Capability.
Lead-Free Finish; RoHS Compliant (Notes 1 & 2).
Halogen and Antimony Free. “Green” Device (Note 3).
The SMAJ5.0(C)AQ.
SMAJ200(C)AQ is suitable for automotive.
