MBR1040CT - 10A SCHOTTKY BARRIER RECTIFIER

Diodes

📥 Download Datasheet

MBR1040CT Datasheet Preview — Preview of MBR1040CT PDF

Datasheet Details

Part number	MBR1040CT
Manufacturer	DIODES
File Size	382.62 KB
Description	10A SCHOTTKY BARRIER RECTIFIER
Datasheet	MBR1040CT-Diodes.pdf

MBR1040CT Product details

Description

and Applications This Schottky Barrier Rectifier is designed to meet the general requirements of commercial applications. Polarity Protection Diode Re-Circulating Diode Switching Diode Case: TO220AB Case Material: Molded Plastic, “Green” Molding Compound; UL Flammability Classification Rating 94V-0 Moisture Sensitivity: Level 1 per J-STD-020 Terminals: Finish - Matte Tin Annealed over Copper Leadframe.

Features

MBR1040CT.
MBR1045CT (Per Leg) VRRM (V) IO (A) VF (MAX) (V) @ +25°C 40 , 45 5 0.65 MBR1060CT-I (Per Leg) VRRM (V) 60 IO (A) 5 VF (MAX) (V) @ +25°C 0.75 IR (MAX) (mA) @ +25°C 0.1 IR (MAX) (mA) @ +25°C 0.1.
Guard Ring Die Construction for Transient Protection.
High Surge Current Capability.
Low Forward Voltage Drop.
Lead-Free Finish; RoHS Compliant (Notes 1 & 2).
Halogen and Antimony Free. “Green” Device (Note 3).
Qualified to AEC-Q101 Standards.
