DDZ12C - SURFACE MOUNT PRECISION ZENER DIODE

Download the DDZ12C datasheet PDF (DDZ5V1B included). The manufacturer datasheet provides complete specifications, pinout details, electrical characteristics, and typical applications for surface mount precision zener diode.

Features

  • Very Tight Tolerance on VZ.
  • Ideally Suited for Automated Assembly Processes.
  • Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2).
  • Halogen and Antimony Free. “Green” Device (Notes 3 & 4).
  • Qualified to AEC-Q101 Standards for High Reliability Mechanical Data.
  • Case: SOD123.
  • Case Material: Molded Plastic, “Green Molding Compound”. UL Flammability Classification Rating 94V-0.
  • Moisture Sensitivity: Level 1 per J-STD-020.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (DDZ5V1B-Diodes.pdf) that lists specifications for multiple related part numbers.
