MBR6030PT - 60A SCHOTTKY BARRIER RECTIFIER

Name: MBR6030PT
SKU: MBR6030PT-395463

Diodes Incorporated

The MBR6030PT by Diodes Incorporated is a 60A SCHOTTKY BARRIER RECTIFIER. Below is the official datasheet preview.

Datasheet Details

Part number	MBR6030PT
Manufacturer	DIODES Incorporated
File Size	572.61 KB
Description	60A SCHOTTKY BARRIER RECTIFIER
Datasheet	MBR6030PT_DiodesIncorporated.pdf
Additional preview pages of the MBR6030PT datasheet.

Schottky Barrier Chip.
Guard Ring Die Construction for Transient Protection TO-3P.
Low Power Loss, High Efficiency Dim Min Max.
High Surge Capability A 1.88 2.08.
High Current Capability and Low Forward Voltage Drop.
For Use in Low Voltage, High Frequency Inverters, Free H A B 4.68 5.36 B C 20.63 22.38 Wheeling, and Polarity Protection.
