FM25CL64B - 64-Kbit (8 K x 8) Serial (SPI) Automotive F-RAM

Cypress Semiconductor

Datasheet Details

Part number	FM25CL64B
Manufacturer	Cypress Semiconductor
File Size	731.30 KB
Description	64-Kbit (8 K x 8) Serial (SPI) Automotive F-RAM
Datasheet	FM25CL64B-CypressSemiconductor.pdf

64-Kbit ferroelectric random access memory (F-RAM) logically organized as 8 K × 8.
High-endurance 10 trillion (1013) read/writes.
121-year data retention (See the Data Retention and Endurance table).
NoDelay™ writes.
Advanced high-reliability ferroelectric process.
Very fast serial peripheral interface (SPI).
Up to 16 MHz frequency.
Direct hardware replacement for serial flash and EEPROM.
Supports SPI mode 0 (0,0) and mode 3 (1,1).
Sophisticated.
