__ Coaxial Attenuators _ MECHANICAL SPECIFICATIONS Connector: Housing: Insulator: www.DataSheet4U.com Brass, Nickel Plated.

Aluminum, Nickel Plated per QQ-N-290.

PTFE, Virgin grade.

50 Ω.

high power coaxial attenuators product selection chart Connectors Width Height SMA Male SMA Female SMA Male & Female N Male N Female N Male & Female 1.770" 1.500" 1.635" 2.640" 2.520" 2.580" 1.000" 1.000" 1.000" 1.000" 1.000" 1.000" Impedance: P/N CHA-20 SM CHA-20 SF CHA-20 SMF CHA-20 NM CHA-20 NF CHA-20 NMF
