CA-IS3620 - Reinforced Digital Isolators

Description

The CA‐IS36xx family integrated signal and power isolation devices simplify system design and reduce board area.

These devices are high‐performance, dual‐channel and four‐channel, unidirectional reinforced digital isolators with up to 5kVRMS isolation rating and ultra‐fast data rate.

Features

  • Integrated High‐efficiency DC‐DC Converter withon‐ chip Transformer.
  • Regulated output options: 3.3 V or 5.0 V.
  • Up to 650mW output power.
  • Soft‐start to limit inrush current and overshoot.
  • Overload and short‐circuit protection.
  • Thermal shutdown.
  • Low emissions.
  • Robust Galvanic Isolation of Digital Signals.
  • High lifetime: > 40 years.
  • Withstands 5kVRMS for 60s.
  • ±150 kV/μs typical CMTI.
  • Schmitt trigger inputs.
  • Interfaces Dir.

📥 Download Datasheet

Datasheet preview – CA-IS3620

Datasheet Details

Part number CA-IS3620
Manufacturer Chipanalog
File Size 1.01 MB
Description Reinforced Digital Isolators
Datasheet download datasheet CA-IS3620 Datasheet
Additional preview pages of the CA-IS3620 datasheet.

📁 Similar Datasheet

  • CA-050x - Current Transformers & Sensors (Premo)
  • CA-100x - Current Transformers & Sensors (Premo)
  • CA-200x - Current Transformers & Sensors (Premo)
  • CA-254CS - Cable (Tensility International)
  • CA-254S - Cable (Tensility International)
  • CA-301 - CYLINDER (Epson ToYoCom)
  • CA-354S - Cable (Tensility International)
  • CA-356CS - Cable (Tensility International)
  • CA-D240 - Service Manual (Aiwa)
  • CA-MLF32A-A-Z-T-01 - Carrier Adaptor (Ironwood Electronics)
Other Datasheets by Chipanalog

Full PDF Text Transcription

Click to expand full text
Shanghai Chipanalog Microelectronics Co., Ltd. CA‐IS3620, CA‐IS3621 CA‐IS3640, CA‐IS3641, CA‐IS3642, CA‐IS3643, CA‐IS3644 Version 1.08 CA‐IS36xx High‐performance, 5kVRMS Reinforced Digital Isolators with Integrated high‐efficiency, Low‐emissions DC‐DC Converter 1 Features • Integrated High‐efficiency DC‐DC Converter withon‐ chip Transformer  Regulated output options: 3.3 V or 5.0 V  Up to 650mW output power  Soft‐start to limit inrush current and overshoot  Overload and short‐circuit protection  Thermal shutdown  Low emissions • Robust Galvanic Isolation of Digital Signals  High lifetime: > 40 years  Withstands 5kVRMS for 60s  ±150 kV/μs typical CMTI  Schmitt trigger inputs • Interfaces Directly with Most Micros and FPGAs  Data rate: DC to 100Mbps  3V to 5.
