CAT5241 - Quad Digitally Programmable Potentiometers

Catalyst Semiconductor

Datasheet Details

Part number	CAT5241
Manufacturer	Catalyst Semiconductor
File Size	111.15 KB
Description	Quad Digitally Programmable Potentiometers
Datasheet	CAT5241_CatalystSemiconductor.pdf

The CAT5241 is four Digitally Programmable Potentiometers (DPPs™) integrated with control logic and 16 bytes of NVRAM memory.

s Four linear-taper digitally programmable H GEN FR ALO EE LE A D F R E ETM s Automatic recall of saved wiper settings at potentiometers s 64 resistor taps per potentiometer s End to end resistance 2.5kΩ, 10kΩ, 50kΩ or 100kΩ s Potentiometer control and memory access via power up s 2.5 to 6.0 volt operation s Standby current less than 1µA s 1,000,000 nonvolatile WRITE cycles s 100 year nonvolatile memory data retention s 20-lead SOIC and TSSOP packages s Industrial temperature range 2-wi.
