cosmo
z Features：
Photo Coupler for AC Power TRIAC Output
z
KTLP3527
Outside Dimension：Unit ( mm )
1. Compact dual-in-line Package. 2. 600V peak blocking voltage. 3. Isolation voltage between input and output 2500Vrms. z Application： 1. TRIAC Driver. 2. Programmable Controllers. 3. AC-Output Module. 4. Solid State Relay.
ZC
z
Schematic：Top View
15 13 11 9
2
3
4
5
6
7
2：Anode 3：Cathode 4,5,6,7：N.C 9,13：TRIAC T2 11：TRIAC T1 15：TRIAC Gate RATING 50 -0.7 1 5 125 600 1.0 0.7 -14.
