ISO120 - Precision Low Cost ISOLATION AMPLIFIER

Download the ISO120 datasheet PDF. This datasheet also covers the ISO120_Burr variant, as both devices belong to the same precision low cost isolation amplifier family and are provided as variant models within a single manufacturer datasheet.

Description

The ISO120 and ISO121 are precision isolation amplifiers incorporating a novel duty cycle modulationdemodulation technique.

The signal is transmitted digitally across a 2pF differential capacitive barrier.
