STXW, Sealed Tact Switch

www.DataSheet4U.com IA NT .

STXW_BournsElectronic.pdf

STXW Datasheet Preview — Preview of STXW PDF

Datasheet Details

Part number:

STXW

Manufacturer:

Bourns Electronic

File Size:

253.82 KB

Description:

Sealed Tact Switch

Features

* Through-hole and SMD styles available Available sharp click feel with a positive tactile feedback Ultra-miniature and lightweight structure suitable for high density mounting Designed for washing after soldering RoHS compliant
* R oH S CO The ST(H,M,J,R)W

Applications

* ST(H,M,J,R)W Series Sealed Tact Switch Packaging Specifications STJW STMW STRW 7.85 ± 0.10 (0.31 ± .004) 4 ± 0.10 (0.16 ± .004) 16.00 +0.30/-0.10 (.630 + .012/-.003) 5.5 ± 0.10 (0.22 ± .004) How to Order STM W - 6 60 - N TR Model STM = SMD “G” style STH = Through-hole STJ = SMD “J” style STR = S
