Datasheet Details
| Part number | BL128128C2 |
|---|---|
| Manufacturer | Bolymin |
| File Size | 243.55 KB |
| Description | LCD Module |
| Datasheet |
 BL128128C2-Bolymin.pdf
|
| Part number | BL128128C2 |
|---|---|
| Manufacturer | Bolymin |
| File Size | 243.55 KB |
| Description | LCD Module |
| Datasheet |
BL128128C2-Bolymin.pdf
|
1 Vss 0V Ground 2 Vdd 3.3V Supply voltage for logic 3 CS H/L Chip select pin 4 /RES H/L Hardware Reset pin 5 D/C H/L H: Data; L: Command.8080: data write enable pin 6 RW H/L 6800: Read/Write select pin 8080: data read enable pin 7 E H/L 6800: Read/Write enable pin 8 DB0 H/L Data bus line 9 DB1 H/L Data bus line 10 DB2 H/L Data bus line 11 DB3 H/L Data bus line 12 DB4 H/L Data bus line 13 DB5 H/L Data bus line 14 DB6 H/L Data bus line 15 DB7 H/L Data bus line
