BP3316D PSR Single-Stage APFC Offline LED Driver

BPS

BP3316D Description

BP3316D PSR Single-Stage APFC Offline LED Driver .
The BP3316D is a high precision primary-side regulation driver with single stage Active PFC, specially designed for universal input offline flyback or.

BP3316D Features

* Single-Stage Active PFC for High Power Factor and Low THD
* Primary Side Control Constant Current Operation, No Opto-Coupler required
* Integrated 650V Power MOSFET
* ±3% LED Current Accuracy
* Excellent Line and Load Regulation
* Critical Conduction Mode Operation
* Ul

BP3316D Applications

* LED Bulb, Spot Light
* PAR30, PAR38 LED Lamp
* T8/T10 LED String
* Other LED Lighting NP NS AC NA BP3316D 2 VCC DRAIN 5 3 FB DRAIN 6 1 COMP 4 CS GND 7 GND 8 BP3316D_EN_DS_Rev 1.0 Figure 1. Typical application circuit for BP3316D www. bpsemi. com Bright Power Semiconductor C

📥 Download Datasheet

BP3316D Datasheet Preview — Preview of BP3316D PDF

Datasheet Details

Part number: BP3316D
Manufacturer: BPS
File Size: 335.65 KB
Datasheet: BP3316D-BPS.pdf
Description: PSR Single-Stage APFC Offline LED Driver
