HMC819LC5 GaAs MMIC I/Q UPCONVERTER

HMC819LC5 Description

v04.0614 HMC819LC5 GaAs MMIC I/Q UPCONVERTER 17.6 - 23.7 GHz Mixers - I/Q Mixers, IRMS & Receivers - SMT Typical Applications .
The HMC819LC5 is a compact GaAs MMIC I/Q upconverter in a leadless RoHS compliant SMT package.

HMC819LC5 Features

* The HMC819LC5 is ideal for: High Conversion Gain: 15 dB
* Point-to-Point and Point-to-Multi-Point Radio Excellent Sideband Rejection: -35 dBc
* Military Radar, EW & ELINT 2 LO to RF Isolation: 12 dB
* Satellite Communications High Output IP3: +35 dBm
* Sensor

📥 Download Datasheet

Preview of HMC819LC5 PDF
datasheet Preview Page 2 datasheet Preview Page 3
