HMC605LP3E, HMC605LP3 GaAs PHEMT MMIC

HMC605LP3E Description

LOW NOISE AMPLIFIERS - SMT HMC605LP3 / 605LP3E v04.1013 GaAs PHEMT MMIC LOW NOISE AMPLIFIER w/ BYPASS MODE, 2.3 - 2.7 GHz Typical Applications F.
The HMC605LP3 / HMC605LP3E are versatile, high dynamic range GaAs MMIC Low Noise Amplifi ers that integrate a low loss LNA bypass path on the IC.

HMC605LP3E Features

* The HMC605LP3 / HMC605LP3E is ideal for: Noise Figure: 1.1 dB
* Wireless Infrastructure Output IP3: +31 dBm
* Customer Premise Equipment Gain: 20 dB
* Fixed Wireless Low Loss & Failsafe Bypass Path
* WiMAX & WiBro
* Tower Mounted Amplifiers Single Su

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: HMC605LP3E, HMC605LP3. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
HMC605LP3E, HMC605LP3
Manufacturer
Analog Devices ↗
File Size
751.38 KB
Datasheet
HMC605LP3-AnalogDevices.pdf
Description
GaAs PHEMT MMIC
Note
This datasheet PDF includes multiple part numbers: HMC605LP3E, HMC605LP3.
Please refer to the document for exact specifications by model.
