HMC420QS16E, HMC420QS16 CELLULAR RFIC DOWNCONVERTER

HMC420QS16E Description

HMC420QS16 / 420QS16E v03.0810 CELLULAR RFIC DOWNCONVERTER, 0.7 - 1.0 GHz MIXERS - DOWNCONVERTERS - SMT 9 9-1 Typical Applications .
The HMC420QS16 & HMC420QS16E are linear downconverter receiver ICs suitable for cellular infrastructure applications from 0.

HMC420QS16E Features

* The HMC420QS16 / HMC420QS16E is ideal for: +15 dBm Input IP3
* GSM & CDMA Infrastructure Integrated IF & LO Amps: 0 dBm LO
* GPRS & EDGE Infrastructure Conversion Gain: 12.5 dB
* Wireless Data/CDPD Noise Figure: 13 dB OLETE Functional Diagram Single Positive Supply:

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: HMC420QS16E, HMC420QS16. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
HMC420QS16E, HMC420QS16
Manufacturer
Analog Devices ↗
File Size
1.07 MB
Datasheet
HMC420QS16-AnalogDevices.pdf
Description
CELLULAR RFIC DOWNCONVERTER
Note
This datasheet PDF includes multiple part numbers: HMC420QS16E, HMC420QS16.
Please refer to the document for exact specifications by model.
