ADRF6658 - Dual Rx Mixers

Description

Wideband, dual-channel, active downconversion mixers Low distortion, fast settling, IF DGAs RF input frequency range: 690 MHz to 3.8 GHz Programmable baluns on RF inputs For RF = 1950 MHz, IF = 281 MHz, high linearity mode Voltage conversion gain, including IF filter loss: 5 dB to +26.5 dB
