FKC05 Datasheet - Amtex

FKC05 5 WATT DC DC CONVERTER

FK C05 SERIES FKC05 DC/DC Single & Dual Converters: 5 Watts Specifications INPUT VOLTAGE: 12VDC 24VDC 48VDC Pi type (9 - 18) (18 - 36) FKC05-W (9-36) (36 - 75), FKC05-W (18-75) INPUT FILTER: INPUT SURGE VOLTAGE: (100ms max.) EFFICIENCY: START UP TIME: VOLTAGE ACCURACY: VOLTAGE ADJUSTMENT: MINIMUM LOAD: LINE REGULATION: LOAD REGULATION: RIPPLE & NOISE: 12V/36V, 24V/50V, 48V/100V Model dependent 76~84% 600ms typical with constant resistor load ±2% N/A 0%. (FCK05-W requires 10%) ±0.02% at cons.

FKC05 Features

* Wide input 2:1 range and 4:1 option - W

* Standard 24 PIN or SMD type option - SMD

* Nickel-coated copper shield

* EMC: EN55022. Immunity: EN61000-4

* Isolation: 1600V

* Low ripple and noise

* Safety approvals to EN60950, UL1950

* Hig

FKC05 Datasheet (106.75 KB)

FKC05 Datasheet Preview — Preview of FKC05 PDF

Datasheet Details

Part number:

FKC05

Manufacturer:

Amtex

File Size:

106.75 KB

Description:

5 watt dc dc converter.
