AOZ8S204BLS-24 - Single Channel Bidirectional TVS Diode

General Description

The AOZ8S204BLS-24 is a single channel transient voltage suppressor designed to protect high speed data lines and voltage sensitive electronics from high transient conditions and ESD.

The AOZ8S204BLS-24 comes in an RoHS compliant package and is rated over a -40°C to +125°C ambient temperature range.

Key Features

  • -.
  • ESD protection for high-speed data lines: IEC 61000 4-2, ESD immunity:.
  • Air discharge: ±20 kV.
  • Contact Discharge: ±20 kV - IEC 61000-4-5 (Lightning 8/20 µs): 8.5 A - IEC 61000-4-4 EFT (5/50 ns): 40 A - Human Body Mode: ±8 kV.
  • Bidirectional TVS.
  • Low capacitance: 0.15 pF.
  • Low clamping voltage.
  • Low operating voltage: 24 V.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
AOZ8006 Ultra-Low Capacitance TVS Diode Array ALPHA & OMEGA
AOZ1015 EZBuck 1.5A Synchronous Buck Regulator Alpha and Omega Semiconductors
AOZ1017 EZBuck 3A Simple Regulator Alpha and Omega Semiconductors
AOZ1018 EZBuck 2A Simple Regulator Alpha and Omega Semiconductors
AOZ1019 EZBuck 2A Simple Regulator Alpha and Omega Semiconductors

Other Datasheets by Alpha & Omega Semiconductors

Part Number Description
AOZ8S204BLS-30 TVS Diode
AOZ8S204BLS TVS Diode
AOZ8S204BL2 Dual Channel Bidirectional 0.15pF TVS Diode
AOZ8S203BLS Single Channel Bidirectional TVS Diode
AOZ8S205BL2 Dual Channel Bidirectional TVS Diode

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
ALPHA & OMEGA SEMICONDUCTOR AOZ8S204BLS-24 Single Channel Bidirectional 0.15pF TVS Diode General Description The AOZ8S204BLS-24 is a single channel transient voltage suppressor designed to protect high speed data lines and voltage sensitive electronics from high transient conditions and ESD. The AOZ8S204BLS-24 comes in an RoHS compliant package and is rated over a -40°C to +125°C ambient temperature range. The ultra-small 0.6 mm x 0.3 mm 0201 footprint package makes the AOZ8S204BLS-24 ideal for applications where PCB space is a premium. The small size and high ESD protection makes it ideal for protecting voltage sensitive electronics from high transient conditions and ESD.
