UDN2595 - 8-CHANNEL SATURATED SINK DRIVERS

Allegro MicroSystems

Datasheet Details

Part number	UDN2595
Manufacturer	Allegro MicroSystems
File Size	79.52 KB
Description	8-CHANNEL SATURATED SINK DRIVERS
Datasheet	UDN2595_AllegroMicroSystems.pdf

s Non-Inverting Function (Input Low = Output ON) s 200 mA Current Rating s 100 mA Continuous and Simultaneous (All outputs) to +85°C s Low Saturation Voltage s TTL, CMOS, NMOS Compatible s Efficient Input/Output Pin Format s DIP or SOIC Packaging Package Power Dissipation, PD See Graph Operating Temperature Range, TA -20°C to +85°C Always order by complete part number: Part Number Package Storage Temperature Range, TS -55°C to +150°C UDN2595A 18-Pin DIP A2595SLW 20-Lead Wide-Body SOIC 25.
